WEISS™ WBL290F Metal Lathe Benchtop Brushless Lathe-11.5"x29"

$2031.9

≥1 Piece/Pieces

Payment:

Product Attributes



Product Attributes

Model No.: WEISS™ WBL290F Metal Lathe Benchtop Brushless Lathe-11.5"x29"

Packaging & Delivery

Selling Units

Piece/Pieces

Single package size

59cm*29cm*29cm

Single gross weight

590kg

Lead Time

Quantity（Piece/Pieces）	1	>1
Est. Time（days)	20	To be negotiated

If you finish the payment today, your order will ship out within the delivery date.

The file is encrypted. Please fill in the following information to continue accessing it

Product Description



Introduction

MODEL NO.: WBL290F / WBL290F-D
INTRODUCTION:

WEISS WBL290F bench lathe is a specially designed machine with an outstanding value and able to take on light duty jobs requiring a 11" swing, 1-1/2" (38mm) spindle bore and 29" between centers.

Standard Accessories

These accessories comes with each machine for no extra charge, including:

· 6" D type directly mounted 3-jaw chuck with two sets of jaws
· Steady rest
· Follow rest
· Face plate
· 250-111 Piston type quick change tool post with 4 holders
· Chuck guard
· Splash guard & oil tray
· Replacement fuse
· MT#3 living center
· MT#3 dead centers and MT3/MT5 center sleeve
· Tool box with service tools
· WBL290F-D come with 2-Axis SINO DRO with grating scales

DESCRIPTION

WEISS WBL290F bench lathe is a specially designed machine with an outstanding value and able to take on light duty jobs requiring a 11" swing, 1-1/2" (38mm) spindle bore and 29" between centers.
The Primary purpose of WBL290F is to make concentric cuts in metal stock. With the lathe, round stock can be made perfectly concentric, threaded, drilled, knurled, bored, tapered, etc.
Real inch leadscrew and all feed screws for even, easy measurements. No need metric conversions.
D1-4 camlock spindle make swapping chucks a lot easier, more precision.
Large 1-1/2" spindle bore.
Power cross feed is available.
Piston Type Quick Change Tool Post set included.
[Optional] 2-axis SINO DRO system with grating scales shows carriage travel and cross slide travel.
Super smooth and quiet running machine.
WEISS factory provides reliable quality, in time service and fast technical support.

SPECIFICATION

Model No.	WBL290F	WBL290F-D
Item No.	10103295	10103295-D
Distance between centers	29"	29"
Swing over bed	11-1/2"	11-1/2"
Swing over cross slide	6-3/4"	6-3/4"
Bed width	7"	7"
Spindle bore	1-1/2"	1-1/2"
Spindle nose	D1-4	D1-4
Spindle taper	MT#5	MT#5
Spindle speeds	50-1800 RPM (Variable)	50-1800 RPM (Variable)
Range of cross feeds	0.0015-0.0056"/rev.	0.0015-0.0056"/rev.
Range of longitudinal feeds	0.0025-0.012"/rev.	0.0025-0.012"/rev.
Inch thread range	(21) 8–56 TPI	(21) 8–56 TPI
Metric thread range	(12) 0.4–3.mm	(12) 0.4–3.mm
Cross slide travel	6-3/4"	6-3/4"
Compound rest travel	3-3/4"	3-3/4"
Tailstock taper	MT#3	MT#3
Tailstock quill diameter	1-1/4"	1-1/4"
Tailstock quill travel	3-1/8"	3-3/8"
Motor type	Brushless, 2HP	Brushless, 2HP
Power supply	110V/1Ph/60Hz	110V/1Ph/60Hz
Rated current	15A	15A
Packing size	59" W × 29-1/2" D × 29" H	59" W × 29-1/2" D × 29" H
Approx. shipping weight	590 lbs.	597 lbs.

DETALIS

Apron

WBL290F apron can provide power cross & longitudinal feed
Feed rod with clutch system and micrometer carriage stop provide more pretection
Feed rod resistance power can be adjusted by the clutch

Change Gears

WBL290F change gears cover is equipped with protective QKS8 door swtich
WBL290F change gears are all metal gears, can provides 21 kinds of inch threads and 12 kinds of metric threads cutting
Both right and left hand threads is available
WBL290F gearbox provides 3 kinds of feeding speeds
Separate leadscrew and feed rod

Tailstock

WBL290F tailstock with quick lock handle
Tailstock lock system features a drive hub to ensure consistent draw-down alignment every time

WBL290F Standard Accessories

WBL290F-D Standard Accessories

· 6" D type directly mounted 3-jaw chuck with two sets of jaws
· Steady rest
· Follow rest
· Face plate
· 250-111 Piston type quick change tool post with 4 holders
· Chuck guard
· Splash guard & oil tray
· Replacement fuse
· MT#3 dead centers and MT3/MT5 center sleeve
· MT#3 living center
· Tool box with service tools

· 2-Axis SINO DRO with grating scales
